| AUDIO SPECIFICATIONS AND FEATURES | |
|---|---|
| Stereo Power | 80 x 2 |
| Amplifier Type | High-current capability, ultrawide-bandwidth amplifier design with low negative feedback |
| High Instantaneous Current Capability | 42 Amps |
| Power Bandwidth | 20Hz – 20kHz |
| Ultrawide Bandwidth Design @ 1W (+0dB / –3dB) | 10Hz – 110kHz |
| Signal-to-noise Ratio (IHF-A) | 95 dB |
| Slew Rate | 40V/µsec |
| Input Sensitivity/Impedance | 200mV/47k ohms |
| Compressed Music Tools | No |
| AUDIO CONNECTIVITY FEATURES | |
|---|---|
| Analog Audio Input (Rear) | 6 |
| Analog Audio Input (Front) | 1 |
| Phono Input | 1 |
| Preamp Outputs/Main Amp Inputs | 1-1 |
| Record Outputs | 1 |
| Subwoofer Output | 1 |
| Headphone Output | 1/4" Jack |
| iPod® Connectivity | Includes A/V Cable |
| A/B Speaker Switching | 1 |
| Speaker Terminals | 2 Sets |
| VIDEO CONNECTIVITY FEATURES | |
|---|---|
| Video Inputs (Rear/Front) | 3-1 |
| Video Outputs | 1 |
| DATA CONNECTIVITY FEATURES | |
|---|---|
| Turn-On Trigger Connections | 2 |
| Software Update Port | Yes |
| IR In / Out Connections | 1-1 |
| REMOTE CONTROL FEATURES | |
|---|---|
| Remote Preprogramming | 1 |
| System Remote Type | IR |
| FM TUNER FEATURES | |
|---|---|
| Usable Sensitivity (IHF) | IHF 1.12µV/13.5dBf |
| Signal-to-Noise Ratio (Mono/Stereo) | Mono/Stereo 73/72dB |
| Distortion (Mono/Stereo) | Mono/Stereo 0.3/0.4% |
| Stereo Separation @ 1kHz | 40 dB |
| Selectivity ±400kHz | 65 dB |
| Image Rejection | 80 |
| IF Rejection | 100 |
| Preset Stations | 30 preset station |
| Direct-Access Tuning | Yes |
| AM TUNER SPECIFICATIONS | |
|---|---|
| Frequency Range kHz | 522 kHz |
| Usable Sensitivity (Loop) | Loop 500µV/M |
| Selectivity | 1kHz, 50% Mod 0.8% |
| Distortion | 9kHz, >25dB |
| OTHER FEATURES | |
|---|---|
| Sirius/XM Radio Compatibility | No |
| Sleep Timer | Up to 90 min |
| Detachable IEC Power Cord | 1 |
| GENERAL SPECIFICATIONS | |
|---|---|
| Power Requirement | AC 230V, 50 Hz |
| Power Consumption (full power/idle) | 1W standby, 230W maximum |
| Switched Accessory AC Outlets | 2- 220-230v 50/60Hz 100W, .5A MAX |
| Dimensions (H x W x D – Metric/English) | 165mm x 440mm x 382mm |
| Weight (Metric/English) | 9.5kg |
